| مكان المنشأ: | شنشى |
| اسم العلامة التجارية: | XZH TEST |
| إصدار الشهادات: | CE/ISO |
| رقم الموديل: | XHGX507C |
| Function | Multiple frequency signal transmission modes |
|---|---|
| Power Supply | 10.8V large capacity rechargeable lithium battery |
| Output Method | Direct connection, coupling, and induction methods |
| Output Frequency | 640Hz to 197kHz (11 selectable frequencies) |
| Output Power | 15W max (9 adjustable levels) |
| Direct Output Voltage | 150Vpp max |
| Display | 5-inch LCD color screen with capacitive touch |
| Dimensions | 320mm × 275mm × 145mm |
| Functions | Pipeline detection, cable identification, A-frame fault finding (optional) |
|---|---|
| Power Supply | 8.4V large capacity rechargeable lithium battery |
| Detection Modes | Broad peak, narrow peak, and valley methods |
| Detection Range | 0-20km (direct connection), 0-10km (coupling) |
| Depth Measurement | 0-20m with ±5% to 10% accuracy |
| Display | 4.3-inch LCD color screen with capacitive touch |
| Dimensions | 350mm × 155mm × 700mm |
| Weight | Approximately 2kg |
| Operating Conditions | -10ºC to 40ºC, ≤80% RH |
