Surge Arrester Counter Action Tester

Name: Surge Arrester Counter Action Tester
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHJS401
Price: 7,970.00 USD
Availability: InStock

تفاصيل المنتج:

مكان المنشأ:	شيان شنشي الصين
اسم العلامة التجارية:	XZH TEST
إصدار الشهادات:	ISO CE
رقم الموديل:	XHJS401

معلومات مفصلة

مكان المنشأ:

شيان شنشي الصين

اسم العلامة التجارية:

XZH TEST

إصدار الشهادات:

ISO CE

رقم الموديل:

XHJS401

الجسم الرئيسي:

φ36×375 ملم

رأس::

φ50×100 ملم

إبراز:

High Light

إبراز:

Independently Developed Surge Arrester Tester,Surge Arrester Counter Action Tester,Counter Action Circuit Breaker Analyzer

Surge Arrester Counter Action Tester

Counter Action Circuit Breaker Analyzer

Trading Information

الحد الأدنى لكمية:

1 مجموعة

تفاصيل التغليف:

التعبئة الخشبية

وقت التسليم:

5-8 أيام عمل

شروط الدفع:

تي/تي

القدرة على العرض:

3000 وحدة / سنة

وصف المنتج

Product Overview

Developed by the technical personnel of our company in response to the needs of power users, the XHJS401 Arrester Counter Operation Tester features an attractive appearance and convenient portability and use, which has replaced the old-fashioned bulky testing instruments and traditional testing methods.

Performance Features

The power switch is located between the instrument body and the head; rotate it 90 degrees in any direction, and a "click" sound indicates that the power is turned on, otherwise, the power is turned off.

Before use, first insert the ground wire into the tail and connect it properly; according to the height of the counter, pull out the telescopic conductive rod of the head to an appropriate length before turning on the power.

After turning on the power, the green light will be on; wait until the red light is on (about 3-5 seconds), then you can test the arrester counter through the telescopic conductive rod of the head.

The instrument can perform repeated tests without turning off the power (the conductive rod should be away from the test product during each charging).

Note: After the test, first turn off the power, then discharge the head conductive rod to the tail ground wire before putting away the instrument. The instrument is powered by four No. 1 batteries, which can support more than 2000 discharge tests. If the battery power is insufficient, the charging time will be prolonged, and the battery should be replaced in time.

Technical Specifications

☆ Dimensions: Main Body: φ36×375mm; Head: φ50×100mm

☆ Weight: 780g

☆ Power Supply: DC 6V (four size 1 batteries)

☆ Output Voltage: 800～1000V

Surge Arrester Counter Action Tester 0
